High quality: We-Unipower, promise to provide you the best quality products ! We check the quality of the goods one by one before shipping out , Ensure the defective rate is 0% !
OEM servise:OEM service is available ! Custom design is welcome !
Product Description
* * * More specs Lithium battery? Contact us ！ * * *
Product Paramenters
|
Basic Parameters
|
Voltage
|
32.5-51.2V
|
|
Capacity
|
100Ah(Standard )
|
|
|
Energy
|
5-20kWh
|
|
|
Internal resistance/Layers
|
≤120mΩ/1-4Layer
|
|
|
Size and weight
|
Thickness
|
400mm
|
|
High
|
916mm
|
|
|
Length
|
680mm
|
|
|
Weight
|
80-215Kg
|
|
|
Electrical Parameters
|
Charging mode
|
constant current
|
|
Charging Current
|
0.5C(Standard)
|
|
|
1C(Maximum constant current@25℃)
|
||
|
Overcharge protection voltage
|
44.8V
|
|
|
Discharge mode
|
constant current
|
|
|
Over-discharge protection voltage
|
58.4V
|
|
|
Discharge Current
|
0.5C(Standard )
|
|
|
1C(Maximum constant current@25℃)
|
||
|
Working Parameters
|
Working Temperature
|
Charging (Small Current):0℃~+45℃
|
|
Discharge(Small Current)-20℃~+55℃
|
||
|
Storage Temperature
|
Conventional storage temperature:-10~+45℃(Three months ,SOC:20%~60%)
|
|
|
Conventional storage temperature:
|
||
|
< 1 month：-5~+45℃
|
||
|
>6 months：0~+35℃
|
||
|
Storage Humidity
|
5%~95%
|
|
|
Transportation Environment
|
Voltage:44.8V~58.4V
|
|
|
SOC:30%~60%
|
||
|
PV parameters
|
Charging current
|
100A
|
|
Discharing current
|
100A
|
|
|
PV input power
|
5.12KW
|
|
|
MPPT voltage range
|
120V-450Vdc
|
|
|
PV voltage range
|
120V-450Vdc
|
|
|
Installation method
|
Floor/removable
|
|
|
System parameters
|
PV input current
|
50A
|
|
Maximum charging current
|
60A
|
|
|
AC input voltage
|
220v/230vdc
|
|
|
Conversion time(inversion)
|
10ms
|
|
|
AC output power
|
5KW
|
|
|
AC output voltage
|
200Vac
|
|
|
AC output frequency
|
50/60Hz
|
|
|
Communication port
|
USB/RS485/WIFI/Bluetooth
|
|
|
IP grade
|
IP21(Indoor)
|
|
|
Cooling method
|
Convection and fan cooling
|
|
|
Safety cerificate
|
CE,RCM,UN383
|
|
|
Design life
|
10years
|
|
|
Optional features
|
Cloud platform management
|
Support intelligent cloud platform/APP
|
|
Optional features
|
Remote intelligent management
|
Support 4G communication
|
|
Battery Management System (BMS)
|
Protection: Low Voltage Disconnect, Short Circuit, Over Voltage,Over Current, Over Charge, Over Discharge, Over Temperature Protection, Internal Cell Balancing, etc.
|
* * * if there are changes in product size and parameters,the actual situation shall prevail * * *
